Sinusoidal (20 mm)

Thicknesses available 0.7mm - 0.75mm
wave height: 20mm
Effective width 1000 mm
Lengths ranges from 40mm to 15,000mm
Steel or Aluminum material, guaranteed product
Availability of all accessories, flashings, trimmings, gutters and curved panels
No items found.
Technical Information

Installation
Guide

Alexpanel hidden fix roof is characterized by its special fixing system consisting of a hidden joint, and exceptional ease of installation. In addition to the innovative solar mounting solution.

Materials
A- Steel According to EN 10346 & ASTM 653M Galvanized, skin passed, pre-painted and top coated steel sheets. Zinc coating: 120-180-275 grams per sqm Alu. Zinc coating: 100-150 grams per sqm B- Aluminum All aluminum rolls used in our production are produced completely according to EN & ASTM & ISO norms. Corrosion resistance Convenient processing properties Decorative appearance
Finishes & Coating
There are surface paint options suitable to the place of use: - Polyester 25 microns - Granite HDX 55 microns – 70 microns - PVDF 25 microns – 35 microns - Plastisol 100 microns – 200 microns - HPS 200 microns Finish color can be selected from RAL catalogue.
Guarantee
Product guarantees on an individual project basis is provided. Typically up to 5 years in a non-marine / geothermal environment. All guarantees are subject to maintenance regime. Specialist coatings are available for marine and other more corrosive areas.
Services
Manufacturing and supplying Technical office: design and detailing Field services: supervision
Construction Details
Our technical team will support you with construction details for your project.
